In today's world, environmental monitoring is the foundation and technical support for environmental management. With the development of my country's environmental protection work, my country's environmental monitoring technology has also made great progress, and the production of environmental monitoring instruments has formed a certain scale. The four-in-one gas detector is a single gas or multiple gas detectors that can be flexibly configured. It can be equipped with an oxygen sensor, a combustible gas sensor, and optionally two toxic gas sensors or optionally four toxic gas sensors or any Choose a single gas sensor.








We know that the conventional four-in-one gas detector can detect four gases: oxygen, combustible gas, hydrogen sulfide, and carbon monoxide. Of course, we can also customize it according to the gas we need to detect. The four-in-one gas detector has a very clear large liquid crystal display screen, with sound and light alarm prompts, to ensure that dangerous gases can be detected in a very unfavorable working environment and promptly prompt the operator to prevent.







The general detection parameters and range of the four-in-one gas detector are as follows:

Can detect 1～4 kinds of gas at the same time, the unit can be switched freely

Units are optional: PPM, mg/m3, Vol%, LEL%, PPHM, ppb, mg/L.

★ Rich man-machine interface

2.31-inch high-definition color screen, displaying real-time concentration, alarm, time, temperature, humidity, storage and other information; the menu interface uses high-definition simulation graphics to display the function name of each menu.

★ Large-capacity data storage function (capacity can be customized), supports multiple storage methods, optional RS485 communication

Therefore, in order to better realize the precise monitoring and control of carbon dioxide content in natural gas, the current more China petroleum co., LTD has introduced Zetron online carbon dioxide analyzer and TH2000-C-CO2-A-H, with its high precision measurement technology and real-time online monitoring function, quickly and accurately detect the carbon dioxide content in natural gas. In this way, enterprises can find and deal with the problem of excessive carbon dioxide content in time, to ensure the stability and environmental protection of the production process. This will not only help to reduce the possibility of accidents, but also to improve the production efficiency and economic benefits of gas enterprises.



Gas industry gas detection solutions:



1. Program background



Terminal CNPC Southwest Oil & Gas Field Branch, medium: natural gas pressure 3.3 MPa, 2.8 Mpa, normal temperature 18℃, components: CH4, C2H6, C3H8, H2S, CO2, N2, H2. Natural gas pipeline measuring CO2,0 ~ 100 PPm (adjustable)



2. Solutions



The overall equipment is of the outdoor type, Can be placed in the open air, The system is equipped with power management and protection system, detector, pumping pump, efficient condensing system, drainage system and other equipment power supply; Equipped with automatic cooling, dehumidification and constant temperature drainage system, The system is equipped with a dust filter and treatment device, Can achieve the purpose of filtering the dust and tar of the measured gas; Detection point pressure maximum of 3.3 MPa, Minimum of 2.8 Mpa, Specification of supporting customized sampling valve: belt / Class600 DN40RJ HG / T 20615-2009; Considering that the detection point is frozen in winter, Power distribution heating system constant temperature control system and 10 meters electric heat tracing pipeline;



3. What product is matched



On-line CO2 analyzer, TH2000-C-CO2-A-H



Dual-stage electronic condensation dehumidification system, power management and protection system, fine dust filtration sampling head (flange installation), long life brushless pump sampling distance of 40 meters, automatic cooling, peristaltic pump drainage, filter tar, reserved manual back interface, sample gas temperature within 600 degrees; suitable for high water vapor, high temperature, the detection and analysis unit is not very high; pump suction detection; with explosion-proof external box;



Detection gas: carbon dioxide CO2; detection range / detection rate / detection principle:



CO2:0-100PPM, 0.01PPM; Imported long life, high precision, high performance, long light range infrared principle sensor;



Concentration unit, display mode, Chinese and English operation interface, 7 inch touch screen operation, import sensor; three wire / four wire system 4-20ma signal + RS485 + relay output;



 Large capacity data storage function (standard 100,000 pieces, larger customizable); multi-mode alarm function, logging function; detector explosion-proof grade: ExdⅡCT6; sampling valve specification: belt / Class600 DN40RJ HG / T 20615-2009; contact medium part is 316 / 304 stainless steel; power distribution heat tracing system and 10 m electric heat tracing pipeline;













In short, through the application of Zetron online carbon dioxide analyzer, it can not only provide reliable products and solutions, but also help gas enterprises to achieve safe production and efficient operation, so as to improve the market competitiveness of enterprises. In the future, Zetron will continue to uphold the concept of professional and innovation, bring more high-quality and efficient solutions to the gas industry, and promote the sustainable development of the whole industry.

About high efficiency filter leak detection: For food and drug manufacturers, high efficiency filter leak detection refers to the on-site leak detection after the installation of high efficiency filter and its system, mainly to check the small pinholes and other damages in the filter material, such as frame seal, gasket seal and leaky seams on the filter frame. The purpose of leak detection is to check the sealing of the high efficiency filter and its connection parts with the installation frame, find the defects in the high efficiency filter itself and in the installation in time, and take corresponding remedial measures to ensure the cleanliness of the area. Whether there is leakage. The purpose of dust generation is that the dust concentration upstream of the high efficiency filter is low, so if a particle counter is used to detect the leak without dust generation, it is difficult to detect the leak, and additional dust generation is needed to obviously and easily detect the leak.











Standards






FED-STD-209E, Par. 50 Federal Standard (Cleanroom and Workstation Requirements)



AACC, CS- 1T American Association for Contamination Control (Standard for High Efficiency Filters)



AACC, CS-2T American Society for Contamination Control (Laminar Flow Clean Air Installation)



AACC, CS-6T American Society for Contamination Control (Clean Room Testing and Certification)



IES, RP-CC-001-3 Institute of Environmental Science (High Efficiency Filters)



IES, RP-CC-002-86 Association for Environmental Science (Recommended Approach for Laminar Flow Clean Air Installations)



IES, RP-CC-001-2 Environmental Science Society (Test Clean Room)



NSF, STD No.49- 1992 National Sanitation Foundation (Secondary Laminar Flow Biological Safety Cabinet)



ANSI, N101.1-1972 American National Standards Institute (Efficiency testing of air cleaning systems with filters)



ANSI/ASME, N5101.198 American National Standards Institute/American Society of Mechanical Engineers (Testing of Nuclear Air Cleaning Systems) NEBB National Environmental Balance Agency (Standard for Clean Room Certification Test Procedures)













Product Information



1.Aerosol photometer PM-350














【Feature】



* The host adopts 5-inch color touch screen, easy to operate and faster data processing



* Intuitive display of leakage rate and pump sampling speed and other data



* Portable scanning probe, 3.5-inch color display, one-touch operation, synchronous display with the host interface, convenient for users to observe the test results



* Automatic switching upstream and downstream



* To ensure reliable and stable data, imported air pump and light source are used







【Parameter】







Data display range





0.0001%-100.0% Multi-color LCD display







Dynamic range





0mg/m3～120mg/m3







Accuracy





1%（ 0.01% to 100%）







Flow control





1cfm（28.3L/min）±10%







Alarm





When the preset limit value is exceeded, 2 modes of audible and visual alarm can be selected







Aerosol type





 PAO, DOP, DEHS and other multi-dispersion







Standards





NSF49、IEST、ISO14644、EN61010-1：2010、EN61326-1:2006







Power





AC 220V  50/60Hz







Dimension





258cm（L）x178cm（W）x360cm（H）







Weight





9.8kg














2. Aerosol generator HRF-4B (cold)







【Features】

* Laskin Nozzle dust production method



* Adjustable manually



* Large capacity loading dust production



【Parameter】








Airborne suspended particle output





range 50 - 8,100 cubic feet per minute (1.4 - 229 m3min)







Suspended Particle Concentration





100 µg/L at 810 cfm flow rate







Suspended Particle Concentration





10 µg/L at 8100 cfm flow rate







Generation type





1 to 7 Laskin nozzles







Compressed air





3 to 18 cubic feet per minute at 20 psi flow







Particle generation





PAO、DOP、polydispersed







Type





 Multiple particle diameters (cold)







Dimensions





25cm（L）X 28cm（W）X23cm（H）












3. Aerosol generator HRF-5C (Hot)









【Feature】

HRF-5C is a more user-friendly enhanced aerosol generator, its oil circuit insurance supply system and thermal cut function in the current market belongs to the higher grade of the security system, suitable for certification, HEPA performance test and installation. Need to use inert gas, suitable for AC220v±10%50HZ power supply.







【Parameter】








Usable flow rate range





1,500-65,000cfm(42-1,839.5m3/min)







Occurrence concentration





10ug/L：flow rate65,000cfm( at approx 1839.5m3/min)







100ug/L：flow rate 6,500cfm(at approx183.95m3/min)







Particle generation





PAO、DOP、polydispersed







Generation method





Heating generation







Compressed gas (inert)





Nitrogen,Argon,Carbon Dioxide或Helium (50psi))







Power supply





AC220～240VAC,50/60HZ







Dimension





280×390×300mm







Weight





14kg








When applying a pressure of 20psi (0.14Mpa) Note: DOP is not recommended







4.Aerosol generator performance comparison table









Model





HRF-4B





HRF-5C









































Principle





Cold generation





Hot generation







Gas source





Compressed air





Inert gas







Gas source pressure





0.4-0.8mpa





50psi







Dust





PAO





PAO







Power





No





AC220～240VAC,50/60HZ








Note: Heating occurs when oily particles are heated and evaporated and then blown into the system air inlet by inert gas, suitable for the end of the whole air conditioning system for high efficiency filter detection, the advantage is that the whole system only needs a place to produce dust , after the filter upstream concentration is stable, you can test the filters one by one, reducing the time of frequent change of dust production points and debugging dust concentration, also saves the PAO oil for debugging. The disadvantage is that there should be a long section of mixed cold generation ten times the diameter of the air duct, which is not suitable for local FFU units without air supply duct at the top, and not suitable for single biosafety cabinets and clean benches.



Cold generation is made of compressed air and pressurized PAO oil, which is sprayed by Laskin nozzles, and the working number of nozzles is used to adjust the size of dust concentration, which is suitable for local FFU units and clean benches of biosafety cabinets without air supply ducts. There is no thermal occurrence of the convenience, there are also air conditioning systems because of the inconvenience of segmentation detection, and can not use this type of dust generation small amount of dust generation instrument.

Lithium batteries are also called lithium-ion batteries, the world's first lithium-ion battery was produced and commercialized by Sony in 1991.

Compared with other rechargeable batteries such as lead-acid batteries and nickel-cadmium batteries, lithium-ion batteries have the advantages of high energy density, relatively safe to use, no memory effect, and do not contain lead, cadmium, mercury and other heavy metal elements that pollute the environment, so it is a more environmentally friendly battery.




The Ministry of Industry and Information Technology (MIIT) promulgated the "New Energy Vehicle Industry Development Plan (2021-2035)" in 2019, which states that the domestic new energy vehicle sales ratio is expected to reach 25% and the intelligent networked vehicle sales ratio to reach 30% by 2025.







Internationally, Europe has introduced the strictest carbon emission law, which will prompt major car companies to accelerate the transition to electrification, and European countries have adopted policies of direct subsidies and tax breaks to promote the long-term development of the industry.



The lithium battery industry chain is divided into upstream materials, midstream lithium-ion batteries and downstream consumer electronics, new energy vehicles and energy storage.



The upstream of the industry chain is the mining and processing of raw material resources, mainly including cobalt, lithium, graphite materials, carbon materials, etc.

The upstream mainly includes cathode materials (lithium carbonate, lithium cobaltate, ternary materials, etc.), anode materials, electrolyte, diaphragm, and other auxiliary materials.



The midstream of the industry chain mainly refers to core manufacturing and modules, connecting upstream core production and downstream vehicle applications.

According to the data in 2020, the power battery installed volume of the top 10 power battery enterprises is 58.4GWh, accounting for 92% of the total installed volume. Enterprises include Ningde Time, Kodaly, Xinwanda, Yiwei Lithium Energy, BYD, and Guoxuan Hi-Tech, etc.



The downstream of lithium battery industry chain includes consumer electronics, new energy vehicles and energy storage.

New energy vehicles are an important thrust of the current lithium battery industry explosion, with new energy vehicle sales rising from 330,000 to 1.21 million units from 2015-2019. The future demand for power batteries for new energy vehicles will continue to grow, and this will greatly increase the market demand for lithium batteries.

In addition, the application of lithium batteries in the field of electric bicycles and energy storage is also developing faster.



Lithium battery production accidents


In addition to the safety of the finished battery, we are also very concerned about the safety of the battery production process. When the electrolyte of lithium battery encounters a large amount of water, it may explode due to rapid decomposition and exotherm. In the working environment of lithium battery factory, there are flammable gas or toxic gas leaks, such as ammonia, CL2, HF, hydrogen sulfide, hydrogen, carbon monoxide, hydrochloric acid, Freon, phosphoric acid, etc. The concentration of these gases exceeds the standard, there will be fire, poisoning and other dangerous hazards.








The process of environmental testing, when the battery is broken, the possibility of CO, H2, H2S leakage will occur, the site distribution and installation of fixed gas detector MIC500, MIC600 can be online detection of leaking low concentration of gases.



Fixed gas detector is suitable for detecting the content of carbon monoxide, hydrogen sulfide and other toxic gases in the gas leakage area. The product adopts the integrated design of sound and light alarm, which can effectively warn the danger of various gas leaks and protect the personal safety of operators.

The gas detectors have their own working conditions. You need to pay attention to the basic conditions of humidity, temperature, and pressure. Generally, the installation in our environmental plant is more suitable. Basically, it can be directly installed and fixed, but we install it in a confined space.








 Such as pipes, flues, in these special environments, we must pay attention to understand the working conditions, our gas detector can adapt to the conditions: normal temperature, -20 degrees to 50 degrees, humidity below 90% Condensation, the pressure is in the range of 100kp.








Once the environmental conditions are not inside, it will affect the accuracy of the measurement and the life of the instrument. At this time, we must consider adding gas pretreatment equipment to perform gas treatment, so that the gas that meets the conditions enters the gas sensor head.
