PTM100-H Handheld Organic Gas Analyzer
- Miniature FID detector with performance comparable to online systems.
- EPC precisely controls hydrogen flow rate to ensure data accuracy.
- Solid-state hydrogen storage cylinder provides safe and stable hydrogen supply.
- Detachable and quickly replaceable battery for long-lasting operation.
- 3.5-inch screen and buttons for two-step detection startup.
- Reserved interface for expandable sensors.
- Stable and reliable signal processing technology.
- Fully digital monitoring and intelligent diagnostics.
- Explosion-proof rating: Ex db ia IIC T4 Gb.
Main parameters
Parameter range
Measuring range
FID: 0～ 45,000 ppm
PID: 0～2,000 ppm , multiple ranges available; [Optional configuration]
Method detection limit
FID: 0.5 ppm methane
PID: 0.5 ppm isobutylene
Accuracy
±5% of reading or ±1 ppm, whichever is greater
±5% of reading or ±1 ppm, whichever is greater
Repeatability
FID: 2% at 500 ppm methane
PID: 1% at 100 ppm isobutylene
Responding to an event (T 90 )
FID: ≤3.5 s (10000ppm methane)
PID: ≤3.5 s ( 5 00ppm isobutylene)
Sampling flow
≥500 ml/ min ( adjustable)
Battery life
≥4 hours (0℃)
Hydrogen endurance
≥ 15 hours
Power adapter
DC8.4 V 1A
Work Environment
-10~45° C , 10 % ~95% RH
Gas interface
1/4 inch
Main parameters
Parameter range
