Zetron PTM600-OZ Ozone Analyser

The PTM600-OZ ozone gas analyser calculates the current ozone concentration by measuring the change in light signal intensity before and after ozone absorption of UV light. The equipment uses an advanced dual-light UV light source system with a lamp intelligent management system, which enables the UV lamp to reach the measurement state quickly after switching on. It is mainly used for continuous detection of ozone gas in various industrial environments, and can also be used to detect ozone gas in operating pipelines, vessels and other environments.

Inquiry

Write a Review

Zetron PTM600-OZ Ozone Analyser

Overview

Features
* Measuring principle: accurate measurement by photometric absorption principle according to Lambert-Beer's law.
* Light source system: Foreign long life UV light source system (wavelength 253.7nm), free 3 year warranty.
* Usage: Indoor installation with power and signal terminals.
* Light cell system: Separate light cell technology, no leakage, high pressure resistance, high flow sampling gas impact resistance.
* Intelligent compensation: built-in temperature and pressure compensation and display, with automatic compensation of the light source.
* Operation mode: User can choose between manual zero calibration and automatic zero calibration according to the operating status, automatic zero calibration time can be set.
* Display units: g/Nm3, mg/NL, %WT, ppm , mg/Nm3 optional.
* Data display: HD colour touch screen, high concentration range setting for incoming gas mass flow rate, real time display of yield.
* Output functions: 4-20mA, RS485 communication, two sets of alarm point output, electronic flow meter input, etc.

* Standard configuration: anti-corrosion flow meter, ozone tail gas destroyer, inlet gas filter.

Model	PTM600-OZ
Measuring range	0-200g/Nm3
Optional ranges	0-300g/Nm3, 0-100g/Nm3, 0-50g/Nm3, 0-1000ppm
Light source life	Approx. 30,000 - 50,000 hours
Sampling method	positive pressure sampling, negative pressure sampling (optional)
Display interface	4.3" touch screen operator interface
Content interface	Ozone concentration, temperature, pressure
Auxiliary functions	Temperature compensation, pressure compensation
Display units	g/Nm3, mg/NL, %WT optional
Display resolution	0.01g/Nm3
Gas flow	0.5L ± 0.2L/min
Input pressure	<0.1 MPa
Concentration error	0.3% FS max
Linearity error	0.2% FS max
Zero point drift	<±0.3%.FS
Response time	0.03 s for signal, 0.3 s for display
Ambient temperature	-20 to 50°C
Piping connection	Quick screw (stainless steel)
Tandem sample aperture	Φ8 (8mm*6mm) (optional)
Bypass sampling aperture	Φ6 (6mm*4mm)
Communication method	RS-485
Output mode	4-20mA (active)
Relay signal	Relay signal for high alarm point, relay signal for low alarm point
Power supply	AC 110-220V
Dimensions	160mm (H) x 260mm (W) x 300mm (D);
Note	1mg/L = 1g/m3 = 467PPM.
Free warranty	24 months (mainframe sensor)

Applicable places
◆ Petrochemical, industrial production, smelting and forging, electric power, coal mine, tunnel engineering, environmental monitoring, sewage treatment.
◆ Bio-pharmaceutical, home environmental protection, animal husbandry, greenhouse cultivation, storage and logistics, brewing and fermentation, agricultural production.
◆ Fire fighting, gas, building construction, municipal enterprises, school laboratory, scientific research center.
◆ Pharmaceutical, spray paint room, paint and coating industry, plastic oven, etc.
