Portable Ozone Detector for Real-Time O3 Gas Monitoring – MIC300-OZ
- Measurement features: patented technology with zero point automatic adjustment function, dual path ultraviolet absorption principle, foreign long-life ultraviolet LED light source, continuous operation, ensuring the stability of detection concentration.
- Test method: Dual path UV absorption method, long-life light source system, high measurement accuracy.
- Measurement principle: According to the Lambert Beer law, accurate measurements are made through the principle of photometric absorption.
- Light source system: Foreign long-life ultraviolet light source system (ultraviolet LED light source with lens), with a free warranty of 2 years.
- Usage: It is recommended to install and use it indoors, equipped with waterproof aviation plugs. Light pool system: Separate light pool technology, leak free, high pressure resistance, and resistance to high flow sampling gas impact.
- Intelligent compensation: Built in temperature and pressure compensation and display, with automa
|
Model |
MIC300OZ |
|
Measuring range |
0-200g/Nm3 (0-300g/Nm3, 0-100g/Nm3, 0-50g/Nm3) |
|
Light source life |
approximately 30000-50000 hours |
|
Sampling mode |
positive pressure sampling |
|
Display interface |
4.3-inch touch screen operation interface |
|
Content interface |
Ozone concentration, temperature, pressure |
|
Auxiliary functions |
Temperature compensation, pressure compensation |
|
Display units |
g/Nm3, mg/NL optional |
|
Display resolution |
0.01g/Nm3 |
|
Gas flow |
0.5L ± 0.2L/min |
|
Input pressure |
<0.1 MPa |
|
Concentration error |
±0.5%FS |
|
Linearity error |
±0.5%FS |
|
Zero point drift |
<±0.3%.FS |
|
Response time |
≤ 1 second |
|
Ambient temperature |
-30~80 ℃ |
|
Piping interface mode |
quick tightening (stainless steel) |
|
Bypass sampling aperture |
Φ6 (6mm*4mm) |
|
Communication method |
RS-485 |
|
Output mode |
4-20mA (active) |
|
Power supply |
24V DC |
|
Dimensions |
120mm (H) × 160mm (W) × 60mm (D), |
|
Note |
1mg/L = 1g/m3 = 467PPM. |
|
Free warranty |
24 months (host) |
