Online Air Quality Monitoring Station for Real-Time AQI Measurement – MIC600-AQI

Continuous Online Ambient Air Monitoring System for Pollution Detection – MIC600-AQI

Measure particles and gas: PM2.5,PM10,CO,SO2,NO2,O3
Upto 5 level calibration points
50,000 pcs data storage
Automatically upload real-time data to cloud platform by 4G. Data can be published on the Internet for easy public access and to raise awareness of current air pollution levels with cloud platform
Signal output: RS485, 4-20mA & Relay
Outdoor design with housing to prevent dust and rain, IP66
2.5-inch high-definition color screen
PISO,CE,FCC, ROHS, ATEX,CNEX,SIL3 Approved
IR controller for remote operation for 15 meters distance
Automatic zero point calibration function

Detection	PM2.5: laser sensor, 0-1000ug/m3, 1ug/m3 resolution
	PM10: laser sensor, 0-1000ug/m3,1ug/m3 resolution
	SO2: Electrochemical sensor, 0-1000ug/m3, 1ug/m3 resolution
	CO: Electrochemical sensor, 0-50mg/m3, 0.01mg/m3 resolution
	NO2:Electrochemical sensor, 0-1000ug/m3, 1ug/m3 resolution
	O3: Electrochemical sensor,0-1000ug/m3, 1ug/m3 resolution
Protection level	IP66
Working environment	Temperature:-40 C ~+ 70 C Humidity:≤10~95% RH(regular)
Weight	2.8Kg
Product Size	500400200mm((L×W×H))
Power supply	220V, 50Hz, input voltage: 24VDC
Respond time	T90≤30S
Protection grade	Ex d II C T6 Gb
Optional communication	with 4G, on the cloud platform
