UV-2300C Wall-mounted Ozone Gas Analyzer

It is mainly used for continuous detection of ozone gas in various industrial environments, and also for detecting ozone gas in operating pipelines, vessels and other environments.

Inquiry Download manual

Details

UV-2300C Ozone Concentration Analyzer

This ozone concentration analyzer is mainly used for ozone concentration measurement in the ozone generator pipeline, and can continuously detect the ozone concentration in the ozone generator outlet pipeline online. It is mainly used for continuous detection of ozone gas in various industrial environments, and can also be used to detect ozone gas in operating pipelines, vessels and other environments. Widely used in pharmaceutical, chemical, municipal, sewage treatment and other industries, the ozone generator outlet concentration and ozone generator output measurement.

     The ozone concentration detector calculates the current ozone concentration value by measuring the change in light signal intensity before and after the absorption of ultraviolet light by ozone. Equipment using advanced dual-optical UV light source system, equipped with lamp intelligent management system, after power on the UV lamp can quickly reach the measurement state, using the German separation of light cell technology, the equipment has no leakage, high pressure resistance, resistance to the impact of large flow sampling gas, easy to clean, easy maintenance, simple operation, low cost of use and other characteristics.

     Ozone concentration detector equipment every 1 hour automatic zero point blowing once to ensure the stability of the zero point, to prevent the zero point drift affect the accuracy of the detection concentration, the gas flow, pressure, flow rate remains unchanged during the calibration zero, to prevent the impact of airflow on the calibration zero, to ensure that the equipment can operate continuously 24 hours a day.

Tag: Exhaust ozone detector, Ozone detector, Ozone concentration online monitor, Ozone generator manufacturer, Tabletop ozone analyzer,Wall-mounted Ozone Gas Analyzer, OEM/ODM services

Parameter

Measuring range 0-300g/Nm3, 0-200g/Nm3, 0-100g/Nm3, 0-14%WT, 0-1000ppm
Display resolution 0.01 g/m3, 0.01ppm Note: 1mg/L=1g/m3=467ppm
Display unit g/Nm3 , mg/NL, %WT , ppm , mg/Nm3
Sampling method Positive pressure sampling , Negative pressure sampling
Content interface Ozone concentration , Temperature compensation, Pressure compensation, Mass flow and production display
Light source life About 30000-50000 hours
Display interface 4.3 inch touch screen operation interface
Auxiliary functions Temperature compensation, pressure compensation
Sampling flow rate 0.5L±0.2L/min
Input pressure <0.1MPa
Concentration error < 0.3%FS
Linearity error < 0.2%FS

Application

Application areas: ozone generator manufacturers, municipal water industry, industrial wastewater industry, fine chemical industry, food and drinking water industry, space disinfection industry, pool disinfection industry, flavor synthesis industry and other industries using ozone generator.
